The Lofoten Floor Mounted Diesel Heater is ideal for boats 35ft-40ft manufactured by Dickinson Marine.

Similar to the Antarctic in performance but with a larger top area, the Lofoten Diesel Heater is a rectangular shape, and a cast-iron lid providing a top cooking surface.

• Lofoten Diesel Heater Requires 4” diameter chimney parts.
• Minimum 4ft or maximum 8ft of chimney is required, a straight run with no elbows work best.
• Chimneys 6ft or longer we highly recommend a barometric damper.
• Permanent fresh air vent needed in the area of the unit.
• Creates a dry heat to dry out the moisture inside the vessel.
• Includes a small cast iron cooktop for cooking etc
• This model has a larger combustion chamber so it produces more heat than the Alaska and Newport heaters
• In sailboat installations, this unit must face fore or aft, if facing port or starboard is desired, the valve would need to be mounted to the side of the unit so the gravity-fed valve won’t starve the burner on heels up to 15 degrees.
• 12v draft assist fan included (can be converted to 24v and 32v). Used for start-up and draft assistance on high fire.
• The valve is calibrated for diesel but can be re-calibrated for kerosene or stove oil.
• 1 turn hot water coil for 5-10 gal or a 2 turn hot water coil for 15-20 gal can be installed for water heating

Width: 10.75″
Height: 18″
Depth: 17″
Weight: 31 lbs (14 Kg)

Fuel Consumption / 24hr:
1.29 gal LOW
3.20 gal HIGH

Heat Output:
Low: 6500 BTU (1.9Kw)
High: 16250 BTU (4.7kW)
